Arctic Freezer 4U-OneX | AmpereOne LGA5964 | Dual 120mm PWM Fans | 151mm Height | 8x 6mm Heat Pipes – New
R1,545.31
Server Cooling Built for the Long Haul
The Arctic Freezer 4U-OneX keeps your AmpereOne-powered server running cool around the clock. With dual ball-bearing fans in a push-pull configuration delivering up to 81 CFM each, your system stays protected against thermal throttling even under the most demanding 24/7 workloads.
Full Coverage from Die to IHS
Most coolers only tackle the die — the Freezer 4U-OneX goes further. Bundled MX-7 thermal paste handles the direct die, while included thermal pads blanket the surrounding integrated heat spreader, ensuring no hot spot is left unchecked.
Rack-Ready Without the Compromise
At just 151mm tall and with 53mm of RAM clearance, the Freezer 4U-OneX slides into standard 4U server chassis and most consumer 4U cases without forcing you to sacrifice memory module options or fight for fitment.
3 in stockIn stock with Supplier - Ships in 2-3 working days
Compare|
TDP Coverage
|
Designed for all AmpereOne® processors (LGA5964) |
|---|---|
|
Thermal Interface Material
|
MX-7 Thermal Paste (0.8 g); Thermal Pad 40 x 6.3 x 2.0 mm x2; Thermal Pad 27 x 7.5 x 2.0 mm x2 |
|
Operating Ambient Temperature
|
0 — 40 °C |
|
Heat Pipes
|
Ø 6 mm x 8 |
|---|---|
|
Number of Fins
|
57 |
|
Fin Material
|
Aluminium |
|
Base Material
|
Custom-engineered copper base |
|
Fan Configuration
|
2x 120mm PWM Fans (Push-Pull) |
|---|---|
|
Fan Speed
|
400 – 3300 RPM, PWM Controlled |
|
Airflow
|
Up to 81 CFM per fan |
|
Fan Bearing
|
Dual Ball Bearing |
|
Typical Voltage
|
12 V DC |
|
Start-Up Voltage
|
3.1 V DC |
|
Current
|
0.29 A |
|
Cable Length
|
300 mm |
|
Connector
|
4-Pin PWM |
|
Dimensions
|
124 (L) x 151 (B) x 156 (H) mm |
|---|---|
|
Net Weight
|
1479 g |
|
RAM Clearance
|
53 mm |
|
Compatible Chassis
|
Standard 4U server racks and most consumer 4U cases |
|
Socket
|
Ampere® LGA5964 (AmpereOne® processors) |
|---|
|
Warranty
|
6 Years |
|---|
